KW-NT1 / KW-AVX820 / KD-AVX77 / KD-AVX40 / KD-AVX44 / KD-ADV49 / KD-ABT22 / KD-BT22 / KD-BT11 / KD-DV9405/9406 / KD-DV9401/9402

Note:

*With KW-NT1, Dialing/Receiving (HFP) and Phonebook transfer functions are only available.

Phonebook transfer will not start automatically.
Click here to go to "How to Transfer the Phonebook".

	: Usable
*1	: Usable, however unstable when call-waiting is in operation
*2	: Usable, but not stable
NG	: Function available on the mobile phone but cannot be used
	: Function unavailable on the mobile phone

The following is a list of things you should know including various potential issues when using Bluetooth functions. Be sure to read it.

General

• Since Bluetooth is wireless communication, there may be cases where normal communication is not available depending on signal quality.
• Mobile phone models listed here have been tested and proven compatible by JVC as of March, 2010. If any modification has been applied to the mobile phone after our test, available functions may be different from the content listed here.
• Compatibility status shown above is applicable to the unit that we have used for the test. This does not guarantee that all units of the same mobile phone model will offer the same result.
• Some functions may require operations from the mobile phone. Refer to the mobile phone's instructions for details.
• Model names or model numbers are trademarks or registered trademarks of their respective holders.
• Devices for PC such as USB Dongle Adapter are not supported.
• Number of characters available for each information display depends on the JVC head unit’s display. All characters may not be displayed in all cases.

Pairing

• JVC head unit may not be located depending on the signal condition or mobile phone setup.
• Before you retry Pairing, please be sure to cancel the Pairing on both the JVC head unit and the device to be connected.
• If the display does not show “Connect”, "Pairing OK" and so on after the Pairing process is completed, Pairing has failed. If so, please retry Pairing after cancelling the Pairing on both the JVC unit and the device to be connected.

Connection

• Even if JVC head unit's Auto Connect function is turned on, there may be instances where only HFP or only A2DP can be connected, as well as the inability to connect to either.
• In cases where errors occur frequently and connection cannot be made, please try again after turning the power off and then turning on again for both the JVC unit and the device to be connected.

Dialing, Receiving (HFP)

• Noise may be generated during a voice call.
• A loud echo may occur during a voice call.
• Depending on the mobile phone model, noise may be generated when switching from call reception to answering the phone.
• Order of the call list for Received, Dialed may not correspond to that on the mobile phone. (Newest record may not be placed on the top.)
• JVC head unit and mobile phone may not always match up properly (e.g. mobile phone doesn't cut the line even when a command is sent from JVC head unit to do so, etc.).
• On certain mobile phones, the other party's phone number may not be displayed properly at call reception, while talking, or while talking to a call-waiting caller.

Phonebook Transfer

Phonebook transfer will not start automatically. The following operations are necessary to initiate/terminate phonebook transfer:

• 1. Set the receiver to the transfer-wait mode (screen display example: RCV 0/50).
• 2. Use the mobile phone to transfer the phonebook entries you desire (individual entries, groups, and/or the entire phonebook can be selected and transferred; actual operation may vary depending on the type of mobile phone used).
• 3. Terminate the transfer-wait mode from the receiver (when maximum memory capacity is reached, the receiver will automatically terminate the transfer-wait mode).

• When transferring phone numbers data from a mobile phone by Phonebook Transfer, text characters that can be recognized on JVC head unit are numerals 0 to 9, + (plus), ＊(asterisk), and # (pound) signs. Unrecognizable characters will be skipped; make sure the correct number has been transfered before making a call from the phonebook.

SMS (Short Message Service) or Text Message Receipt Notification

• Depending on the condition, JVC head unit or the mobile phone may not be notified even though the Receipt Notice mode for SMS or Text Message is turned on.

Battery remainder/ Signal strength indication

• Signal strength indication and battery remainder indication do not necessarily correspond to those on the mobile phone.
• JVC head unit is not compatible with Bluetooth audio players' signal strength and/or battery remainder indications.

Audio (A2DP, AVRCP)

• Sound may be interrupted or playback speed may vary.
• Some mobile phones compatible with HFP only may stream music data. In this case sound quality is low.
• When you receive a call while music streaming is being done in the background, music or noise may be heard for a moment just before ring tone rings.
• During music streaming, the JVC unit's audio control keys may not function as they should depending on the device.
• Certain Bluetooth audio players may continue playback even after changing to a source other than Bluetooth from JVC head unit.
• Certain Bluetooth audio players may not start automatic playback even though Bluetooth is selected as the source from JVC head unit. In such a case, playback using keys on the Bluetooth audio player or JVC head unit.
• Among the Audio Control (AVRCP) functions indicated in the aforementioned chart, only play, pause, forward skip and reverse skip operations have been confirmed.
• To prevent distortion or static noise, adjust the volume level on the wirelessly connected device before use.
